Expanding Foam Kits
is part of the
AB Group
which was established in 1989. Winning the Small
Business
of the Year Award for the Test Valley and Hampshire Area in 2007.
Insulating Spray
Foam
Our DIY Spray
Foam , DIY Insulation Foam or Spray Foam Insulation Kits are ideal if you want
to save yourself hundreds if not thousands of pounds by using disposable
Doing-It-Yourself Foam Kit. Our Portable Self-Propelled Foam Systems are fast
and easy to use. They comprise of two pressurised tanks, linked by hoses, to a
dispensing gun. When the contents of the two tanks are dispensed, they
chemically react to produce a froth-like substance, which quickly expands to
about three to five times the dispensed volume. The foam solidifies in about 60
seconds and fully cures into a solid permanent structure in approximately five
minutes. Cured Closed Cell Foam resists moisture, insulates, dampens noise, adds
structural support, provides an air-seal and fills voids.
Image Showcase
(Mouse
over images to enlarge)
DIY Spray Foam
Polyurethane Foam is the best form of insulation available, because its a
Closed Cell Foam.
‘Quick Cure' fully expands and dries tack-free within 30 seconds. Cut
able in 2-5 minutes. ‘Slow Rise’ fully expands and dries tack-free within 90 seconds. Cat able
in 5-10 minutes
Insulation Spray Foam Systems expand with approximately an 8-to-1 ratio, and
cure to a semi-rigid closed cell foam upon the chemical reaction of component A
(a polymeric isocyanate) with component B (a polyol blend containing certain
additives).
DIY Spray Insulation adheres to almost all building materials with the
exception of surfaces such as polyethylene, Teflon®, silicone, oils and greases,
mould release agents, and similar materials.
Optimal application temperature of Expanding Foam is 24°C (75°F) but may
be sprayed onto colder or warmer substrates, with slight effects on the foam
characteristics. Cured foam is resistant to heat and cold, -129°C to +93°C
(-200°F to +200°F), and to aging, but not UV rays unless painted, covered or
coated. Closed Cell foam is also chemically inert and non-reactive in approved
applications.
Polyurethane Foam systems require no outside mechanical or electrical
power source and are disposable & refillable. Insulation Spray Foam is available
in various kit sizes to meet specific job application requirements. When
sprayed, the foam will create a seamless, continuous seal to insulate and
protect against dust, air infiltration, pests, etc.
BEFORE
AFTER
Typical Quick Cure Applications
Spraying underside of slate tiles, keeps in place,
insulates, water proofs & stop condensation.
Spraying between stud walls, for insulation and sound
proofing.
Spraying wood or metal sheds for insulation and stopping
condensation.
New build or renovation of old properties. (Barn
Conversions)
Spray narrow boats
Insulating commercial & residential construction
Filling openings in boats & trailers
Converting vans & buses
Cold storage warehouses
Noise reduction
Insulating spas & hot tubs
Insulating transportation trailers
Large surface coverage and large voids
Loft and/or Roof insulation
Stage & set design
Skateboard Ramps/Parks
SR Slow Rise
is a multi-purpose slow-rise polyurethane foam. It is formulated to slowly rise
and fill, insulating large enclosed spaces and blind cavities. Expanding Foam SR
Foam is a two-component poured-in-place foam that cures tack-free in 60 to 90
seconds. To help fill cavities and hard to reach areas, you can attach a clear
plastic extension hose to the tip of the nozzle.
Typical Slow Rise applications include:
Insulating refrigerated trailer floors and walls
Sound and noise reduction in walls
Insulation in walls
Filling openings in boats and pontoons
Buoyancy in boats
Filling blind cavities and narrow openings
Now
Available Is a Machine Applied System (CPDS 1000)
CPDS 1000
Constant Pressure Dispensing System
The convenience of disposable foam kits meets the
efficiency of bulk systems in the new CPDS™ 1000 from Touch ’n Seal®. The CPDS
1000 is a portable, constant pressure spray foam dispensing system that uses
compressed air to deliver higher foam yield, up to 2-1/2 times as fast as foam
kits. With minimal investment and training the CPDS 1000 offers an ideal
opportunity for business start-up or service expansion. And with less trash,
less chemical waste, disposable cylinders, and no ozone depleting chemicals,
means you can also feel good about your impact on the environment.
CPDS 1000 System Features
Ideal for business start-up
or service expansion High profit center, low maintenance Eliminates the need for bulk systems in mid-sized projects Ideal for mid-sized projects, rehabs & renovations, repairs, room
additions and "call backs" Commonly available replacement parts 2X faster foam delivery and up to 20% greater yield than disposable
foam kits Foam dispenses from cylinder bottom, resulting in virtually no
chemical waste
Economical - lower cost per board foot than kits
The Touch ‘n Seal
CPDS1000 comes complete, ready to use, just add the appropriate “A” & “B”
chemical cylinder set. The CPDS1000 comes with all necessary tools, an
operational DVD, a 30’ chemical delivery hose set, 2 spray foam applicators, 50
disposable spray nozzles and a set of operational and maintenance manuals.
The CPDS1000 is easily handled and transported by a single individual. It is
ideal for those situations where a rig or bulk system is too much or disposable
kits are too little. Chemical cylinder sets are available for both 1.75 pcf and
1.00 pcf Class 1, Fire Retardant polyurethane spray foam.
Spraying underside of slate tiles, keeps in place,
insulates, water proofs & stop condensation.
