ZEATZ

ZEATZ is a name associated with high quality rotary table solutions was purchased by CNCROTARY.COM in 2003 combining the successful standard range of vertical and horizontal CNC tables from 450mm to 3000mm with additional designs for high quality smaller products, maximising the overall range and making the ZEATZ brand range the largest of any manufacturer anywhere in the World to our knowledge

Zeatz

The Range


CNC rotary tables vertically mounted (horizontal axis)
Model PV
General Milling device long life, small frame with large capacity
Hundreds of units in the field, using spiroid worm technology for heavy duty operation, range from 170 to 300mm diameter, with the option of integral high accuracy encased encoder (unique on standard models). Special easy to use chuck and spindle tool feature (see website pages). Heavy duty carrying capacity and integral hydraulic clamping performance from pneumatic feed

CNC rotary tables vertically and horizontally mounted
Model FHV
Special small stainless steel device for working in harsh environments complete with integral air / hydraulic clamping system, with high accuracy bearing system. The unit will work vertically or horizontally and is of modular construction allowing for multi-spindle variants.

Sizes from 110 to 160mm with various distance between centre options.

CNC rotary tables vertically and horizontally mounted
Model PHV
A range of modular rotary table design structures that will enable most technical solutions to be catered for. Carrying capacities, speeds, fixturing and accuracies are all flexible within the special application design. Hundreds of standard units have been delivered to the market place and have proven to be rugged and robust devices that last for a lifetime of service.

The range starts from 350mm through to 3,000mm and carrying capacities up to 50 tons.

CNC rotary tables horizontally mounted (vertical axis)
Model PH-
A range of devices similar in construction to the PHV, fully modular and variable in design to suit any application, using standard modular components for standard applications.
Carrying capacities, speeds, fixturing and accuracies are all flexible within the special application design. Hundreds of standard units have been delivered to the market place and have proven to be rugged and robust devices that last for a lifetime of service.

The range starts from 450mm through to 3,500mm carrying capacities up to 100 tons.

CNC rotary tilting tables
Model PT2-
The tilting range is cleverly designed using modular parts from other products within the range. The stunning PT220 is constructed using the PV-220 device and the larger models using two PHV units and one PH table. The benefits to the client are that modular construction means reduced delivery times, special designs are easy to produce and that all the parts are just that, modular. No special assembly means any parts or service is easy to carry out and readily available.

The range starts at 220mm through to 3,000mm with capacities up to 50 tons.

CNC rotary tables on linear slides
Model PHL
The rotary linear tables are a beautifully constructed device using linear rollers for the linear actuation, being a cleaner and better and more accurate system than hydrostatics, which incorporate the linear braking system within the rollers. The rotary axis being made up of the linear model PH.

The range starts from 1250mm square up to 3500mm square.

It is important to know that although a modular system, it allows us to produce devices with most sizes and capacities required by the client.

Zeatz

A bespoke design from standard parts. Brilliant!

Zeatz aims for perfection but excellence comes as standard
