We are independent
suppliers of Geothermal equipment and pipes, we offer a wide range
of products and solutions to suit your projects needs.
The range of products we offer has been tailored over the years to
best help solve your requirements through the use of our knowledge
of the European products and of course customer feedback. We offer a
range of cutting edge products with are innovative such as our
modular manifold solutions. |
|
Probes and Pipe |
|
Manufactured from Virgin
Grade Black PE100 High Performance Polyethylene (EN12201)
Go Geothermal offer a “true” geothermal collector pipe:
-
Pipe manufactured
specifically for heat collection-
Available in coil
sizes from 50m to 500 metres
PE100 RC Pipe
(Resistance to Crack) - New Product
Used extensively in mainland Europe PE100-RC Collector pipe offers
superior impact crack resistance to PE100. This product in most soil
conditions negates the use of sand bedding, saving significant
material, plant and labour cost. Conductivity of the sand versus
site soil conditions must always be considered in the analysis
before opting for non sand bed.
A fundamental and critical component of any efficient performing
Ground Source Heat Pump System are the collector pipes where pipe
protection and longevity are paramount. |
|
Chamber Manifolds |
|
Space saving circular
chamber manifolds, made from solid PE pipe offering the following
features:
-
Small diameter,
reduced time excavating on site-
Brass Ball Valve on
the Flow legs-
Returns include
integrated flow meter-
Manifold header – OD
110mmm c/w 1” filling and bleed valve-
All connections are
welded to the chamber wall to ensure its water tight-
S.W.L. – 200Kg-
Lockable cover-
Fully Leak Tested-
63mm Header Pipe
connections-
40mm flow & return
ports (i.e. suitable for 25mm, 32mm & 40mm collector pipe)-
Watertight
|
|
Manifolds |
|
Endorsed by leading Heat
Pump manufacturers including Vaillant, Worcester Bosch & Danfoss our
modular reinforced plastic manifolds remain ever popular. Modular
design, self sealing, pressure tested and simple to install on site,
these versatile modular manifolds are ideally suited for
installation in Plant Rooms, utility rooms or outside in our modular
GeoSTACK chamber.
Unlike inferior manifolds, our manifolds are resistant to corrosion
and freezing - hence they will not crack. To this end we are so
confident in our modular manifolds we now offer a 3 year guarantee. |
|
Chambers |
|
Our Chambers are a high
performance, pre-formed underground access entry points capable of
housing our Manifold solutions. Certified for up to 40 tonnes.
Whilst the GeoSTACK is of a comparable cost to that of traditional
methods such as concrete or brickwork the overall project cost
saving is considerable. The chambers can be built by non-specialist
labour, require no lifting equipment on site, are at full strength
from the moment of installation and fully conform to manual handling
regulations. A typical installation of a 1220x600x900mm deep chamber
will take no longer than 2 hours, including backfilling, whereas a
concrete or brickwork chamber can take anything up to 4 days to
complete.
Developed for quick installations, even in the most difficult
location, the GeoSTACK underground access chamber system is used by
many industries due to its immense strength, light weight,
adaptability and dramatic project cost saving. |
|
Glycol |
|
All of our Heat Transfer
Fluids, pre-commissioning, protection and maintenance solutions are
from UK manufacturers, market leaders in the manufacture of
inhibited glycol products. The brands are synonymous with innovation
and technical excellence and continue to lead the way in safety
critical markets worldwide.
Based on Mono Propylene Glycol (MPG), is a high performance
multi-component heat transfer fluid developed specifically for
ground and air source heat pumps. The physical properties of the
fluid allow it to effectively absorb and transfer heat for use in
residential, commercial and industrial applications.
-
Excellent Freeze
Protection-
Available in 25L, 215L
& 1000 litre containers-
Safe to transport &
handle-
Non Toxic-
Long efficient working
life
|
|
Pre-Insulated Pipe |
|
Go Geothermal has a range
of “leading brand” Pre-Insulated Pipe solutions available in Single
& Twin configurations utilising PE-Xa and Polybutylene carrier
pipes.
-
Available in sizes
25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm, 125mm, 160mm
-
Ideal for transporting
hot water at minimal heat loss
-
Temperature range -15
deg. C to +95 Deg.C
-
Supplied cut to
specific lengths
-
No minimum order
charge
|
|
Fittings |
|
We stock a large range of
high quality Black Electrofusion, Compression and Transition
fittings at extremely competitive prices. Sizes held in stock are
25mm, 32mm, 40mm, 50mm, 63mm, 90mm, 110mm & 125mm. Other sizes can
be obtained usually within 24 hours. |
|
Bentonite High Thermal Conductivity Grout Mix |
|
A blend of quality assured
raw materials, used in conventional Civil Engineering Applications
specifically formulated for use in Geothermal Heat Pump Grouting
Technologies including Ground heat source loops. Offers ease of
mixing, combined with low shrinkage and excellent sealing.
Once mixed with water it remains slightly soft and plastic, thus
insuring continued flexibility to cope with any ground movement and
maintain contact between the ground and probes. |
|
PE-Xa Probes |
|
The REHAU PE-Xa probes,
where only the ultimate solution will suffice. Extremely tough and
able to handle temperatures up to 95°C (perfect for excess heat
storage such as solar - increasingly required feature of new
builds); the PE-Xa really is the next generation of probes.
Furthermore, such is the strength and durability of the PE-Xa probes
we are able to offer a £10,000 consequential loss per PE-Xa probe
installed. Contact us for more details. |
|
Pipe Decoilers |
|
Specifically designed for
the geothermal installer by experienced installers - used in the
field for nearly 2 years before the final design was approved.
Our Spinning Jeni can accommodate most types and size of collector
pipe (i.e. Geothermal Probes/Loops and Horizontal Collector Pipes)
The adjustable frame enables the installer to easily dispense and
recoil if necessary. Assembly takes approximately 5 minutes and will
fit easily into a small van when being transported (when
dissembled). |
|
Ground Source & Air Source Heat Pumps |
|
We stock a range of Buffer
Tanks, Thermal Stores and Expansion Vessels. Please call for more
details. |
|
