Welcome to Belleville Springs Ltd
Belleville springs ltd. has been trading in the spring industry for over
twenty years, as a leading UK stockist of Disc springs and Belleville washers.
Our stock range includes disc spring to Din 2093 & Din 6796 specifications,
Bearing pre-load disc springs. Medium and light duty serrated safety washers and
stainless steel disc springs. A
comprehensive range of compression and extension springs are also carried in
If our stock range cannot meet your requirements, or you would like assistance
in selecting a product for your application, use of our free design, consultancy
and technical support service.
This allows Belleville springs to offer advise on our products. Or with your
requirements in mind design a special spring to suit your application.
By using the wide range of corrosion and temperature resistant alloys available
to us coupled with our experience and knowledge we will design and supply a
spring to meet your requirements.
Disk Spring Definition:
Disk springs were conceived in the mid 1800's, they were invented by Julian
Belleville subsequently naming them the Belleville Washer. In 1867 Julian
Belleville received a patent for the product.
The simple spring device has been progressively advanced to a sophisticated
energy storage system by developments such as turbine and jet systems, internal
combustion engine, oil and gas exploration, nuclear power etc.
Disc Springs arranged into stacked columns can achieve infinitely variable
spring characteristics. They can also be dynamically loaded or statically
Serrated Safety Washers:
The serrated safety Washer is based on the disk spring concept. They have a
unique feature of radial serrations on the convex and concave surfaces.
Tightening of the screw causes final flattening of the safety washer to occur,
the serrations bite into the surface preventing the screw from loosening due to
causes like vibrations etc. The disk spring profile will also assist in keeping
the required screw tension.
The safety Washer and the Belleville Spring Washer offer a reduced outer
diameter than the conventional Disk Spring and are particularly compatible with
hexagonal socket type screws.
They are made from Carbon Spring Steel, upon request surface treatments are
